-40℃ 12.8V 9.6Ah Low Temperature Battery Pack with CE & UN38.3 Certification
Outdoor electronics, defense equipment, and extreme-environment systems makers often have a hard time finding a power option that works in very cold temperatures and meets strict certification standards. For this project, the customer needed a small but strong 12.8V LiFePO4 battery pack that could reliably discharge at -40°C, have a high current flow for peak loads, and meet CE and UN38.3 transport standards.
CM Batteries developed a fully customized low-temperature LiFePO4 pack designed to outperform standard lithium batteries in cold weather environments and ensure long-term operational stability.
Key features：
- Ultra-low temperature operation down to –40°C：Ensures reliable startup and stable operation in extreme cold regions.
- High discharge current 50A for heavy-load devices: Burst current: 80A ≤ 500 ms.
- Full certification for global deployment: Certified to CE and UN38.3 standards, ensuring safe exportation and worldwide compliance.
- Long cycle life ≥1500 cycles: Optimized BMS and pack design deliver over 70% capacity retention after 1500 cycles.
- Wide storage temperature range: Supports stable storage for 3 months at –20°C to +35°C and 12 months at –20°C to +25°C.
| No. | Item | Specification | Note |
|---|---|---|---|
| 1 | Nominal Voltage | 12.8V | 3.2V/Cell |
| 2 | Nominal Capacity | 9.6Ah | @0.2C |
| 3 | Minimum Capacity | 9.45Ah | / |
| 4 | Initial Internal Impedance | ≤80mΩ | AC 1KHZ |
| 5 | Standard Charge Voltage | 14.6V | 3.65V/Cell |
| 6 | Standard Charge Current | 4.8A | |
| 7 | Max. Charge Current | 9A | |
| 8 | Standard Discharge Current | 4.8A | |
| 9 | Max. Discharge Current | 50A | |
| Brust Discharge Current | 80A | ≤500ms | |
| 10 | Discharge Cut-off Voltage | 8.8V | 2.2V/Cell |
| 11 | Cycle Life | ≥1500 cycles | Retention: ≥70% |
| 12 | Charge Temperature | -30°C~50°C | Standard Charge |
| 13 | Discharge Temperature | -40°C ~60°C | Standard Discharge |
| 14 | Storage Temperature | -20°C~ 35°C | ≤3 Months |
| -20°C ~ 25°C | ≤1 Year | ||
| 15 | Weight | About 1.5Kg | / |
| 16 | Special Request | / | / |
4S3P 12.8V 9600mAh 26650 LFP Battery Pack FAQs
What does "4S3P" mean?
It means 4 cells are connected in Series to achieve 12.8V, and 3 cell in Parallel, giving the 9600mAh capacity.
Is the pack available in different dimensions or enclosure types?
Yes. We can redesign the pack layout, shape, thickness, connector type, cable length, and housing according to your device specifications.
Is this battery pack certified for safe shipping?
Yes, this battery pack is certified in accordance with CE and UN38.3.
What protections are included in the battery pack?
The pack supports over-charge, over-discharge, over-current, short-circuit, low-temperature charge protection, and high-temperature cutoff.
What type of charger should I use?
Use a compatible LiFePO4 charger set to 14.6V. Using an incorrect charger may damage the battery or trigger protection. Never charge the pack unattended.
