25.6V 60Ah LiFePO4 Battery Pack for Lifting Motor
Replace Your AGM Battery with a Smarter Lithium Solution. CMB has designed various of custom 25.6V LiFePO4 battery pack for lifting motor. Each solution is customized to your specific needs. We improve the housing raw materials,reducing the weight,larger capacity with the same structure. Our 25.6V 60Ah LiFePO4 battery pack is engineered for seamless AGM battery replacement.
Key features：
- Same dimension,42% lighter
- Configuration: 8S4P (32pcs 32140 LiFePO4 cells)
- Same structure and connector for your current design
- Cycles :2000 times ,80% SOC
- Waterproof: IP65
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 25.6V | 3.2V/cell |
| 2 | Nominal Capacity | 60Ah | @0.2C |
| 3 | Minimum Capacity | 58Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤80mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 29.2V | 3.65V/cell |
| 7 | Standard Charge Current | 12A | @0.2C |
| 8 | Max. Charge Current | 18A | 0℃ ~ +10℃ |
| 25A | +10℃ ~ +50℃ | ||
| 12A | +50℃ ~ +60℃ | ||
| 9 | Standard Discharge Current | 12A | @0.2C |
| 10 | Max. Discharge Current | 30A | |
| 11 | Burst Discharge Current | 100±15A | ≤350ms |
| 12 | Discharge Cut-off Voltage | 20V | 2.5V/cell |
| 13 | Cycle Life | ≥1500cycles | Retention: ≥70% |
| 14 | Charge Temperature | 0°C~+60°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~+60°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ +45°C | ≤3 Months |
| +10°C~ +25°C | ≤1 Year | ||
| 17 | Weight | About 11.1 | kg |
| 18 | Special Request | / | / |
25.6V 60Ah LiFePO4 Battery Pack FAQs
What are the main advantages of this 25.6V 60Ah LiFePO4 battery compared to a traditional AGM battery for a lifting motor?
This battery pack is specifically engineered as a direct upgrade replacement for AGM batteries. The key advantages include a significant weight reduction (due to improved housing raw materials), a larger usable capacity within the same physical structure, and the longer lifecycle and safety benefits inherent to LiFePO4 chemistry.
Does CMB offer customization for lifting motor batteries, or is this a standard model?
The 25.6V 60Ah model is one example of a custom solution we have previously designed for a client. CMB specializes in tailored solutions. If your lifting motor has specific requirements regarding dimensions, communication protocols (like CAN bus or RS485), or terminal types, we can design a custom 25.6V LiFePO4 battery pack to meet your exact needs.
How does the weight reduction of the housing impact the performance of the lifting equipment?
We have enhanced both the appearance and structural integrity of the housing by using an aluminum alloy instead of traditional plastic or steel. This material choice significantly reduces the overall weight.
What is the expected cycle life of this 25.6V 60Ah LiFePO4 battery, and how does it compare to AGM?
This LiFePO4 battery pack is designed for exceptional longevity. It typically offers over 2000 deep charge/discharge cycles 80% SOC, which is approximately 2-3 times longer than a traditional AGM battery.
