3.7V 7200mAh High Temp LiPo Battery Solution for Automotive T-Box & IoT
In the demanding environment of automotive IoT and telematics—such as Car T-Box systems—devices must operate continuously within confined spaces while maintaining reliability under extreme heat. Conventional consumer-grade LiPo batteries often fall short under these conditions, leading to reduced lifespan, unstable power output, and potential safety concerns.
To address these challenges, CMB has developed a high-temperature-resistant 3.7V 7200mAh high temperature lipo rechargeable battery, delivering stable power, superior thermal endurance, and long-term reliability.
Key features：
- Extended Thermal Tolerance: Supports discharge temperatures up to 80°C, maintaining stable performance in vehicle environments.
- Improved Capacity-to-Size Ratio. 7200mAh capacity achieved within a compact 35 × 55.5 × 68 mm footprint.
- Stable Power Output.Controlled charge and discharge currents ensure consistent voltage for communication modules.
- Balanced Charging Design. 0.72A standard charge current reduces thermal stress and extends service life.
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 3.7V | 3.7V/cell |
| 2 | Nominal Capacity | 7200mAh | @0.2C |
| 3 | Minimum Capacity | 6840mAh | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤35mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 4.2V | 4.2V/Cell |
| 7 | Standard Charge Current | 0.72A | |
| 8 | Max. Charge Current | 1.44A | |
| 9 | Standard Discharge Current | 1.44A | |
| 10 | Max. Discharge Current | 2.88A | / |
| 11 | Burst Discharge Current | 5.76A | ≤5s |
| 12 | Discharge Cut-off Voltage | 3V | 3V/Cell |
| 13 | Cycle Life | ≥300cycles | Retention: ≥80% |
| 14 | Charge Temperature | 10°C~45°C | Standard Charge |
| 15 | Discharge Temperature | 0°C ~80°C | Standard Discharge |
| 16 | Storage Temperature | -10°C~ 45°C | ≤3 months |
| 0°C~ +35°C | ≤1 year | ||
| 17 | Weight | About 122g | / |
| 18 | Special Request | / | / |
3.7V 7200mAh LiPo Battery Pack FAQs
Why is high-temperature resistance critical for T-Box batteries?
T-Box units are often installed in enclosed vehicle areas where heat accumulates. Batteries without thermal tolerance experience faster aging and unstable output.
Can the battery dimensions be adjusted for other enclosures?
Yes. CMB supports mechanical and electrical customization based on enclosure constraints.
Is this battery suitable for large-scale production programs?
Yes. The battery design supports stable supply, consistent quality, and batch-level performance control. This is essential for long-term automotive or IoT platform projects.
What certifications or compliance support are available?
CMB supports battery designs aligned with UN38.3, MSDS, and relevant safety standards. Certification support can be adjusted based on project market and regulatory requirements. This helps shorten approval timelines for automotive electronics.
