7S8P 25.2V 40Ah 21700 Li ion Battery Pack
Our 25.2V 40Ah 21700 Battery Pack delivers unwavering power and reliability for all your underwater and marine adventures. Designed to excel in humid, salt-rich environments, it boasts superior water and corrosion resistance—making it the ideal energy solution for professional diving equipment and critical marine operations.
With its high energy density and extended lifespan, this battery supports prolonged missions without interruption. Focus on your exploration; power will never be a concern.
Safety is integral to its design. Equipped with comprehensive protection mechanisms—including safeguards against overcharging, over-discharging, and thermal runaway—this battery ensures maximum stability and peace of mind in offshore and subsea applications.
Integrated BMS with Multi-Level Protection: The built-in Battery Management System provides cell balancing, overcharge protection, and over-discharge protection. This ensures operational safety and stability, minimizing risks associated with improper usage or extreme environments.
Key features：
- IP68 Metal Housing: Engineered with a fully sealed metal structure, this housing delivers exceptional waterproof and corrosion-resistant properties. It is ideal for diving and marine operations.
- 7S8P 21700 High-Capacity Configuration (40Ah): Utilizing high-energy-density 21700 cells, this battery pack offers extended runtime and high power output. It is designed to meet the demands of prolonged missions and high-load applications.
- Customizable Design: Tailored specifications—including voltage (25.2V), capacity (40Ah), dimensions, and connectors—allow seamless compatibility with various diving and marine equipment. This custom approach eliminates integration issues and simplifies installation.
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 25.2V | 3.6V/Cell |
| 2 | Nominal Capacity | 40Ah | @0.2C |
| 3 | Minimum Capacity | ≥39Ah | |
| 4 | Shipment Voltage | 21.7V~27.3V | |
| 5 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 29.4V | 4.2V/Cell |
| 7 | Standard Charge Current | 8A | 0.2C |
| 8 | Max. Charge Current | 40A | 1C |
| 9 | Standard Discharge Current | 20A | 0.5C |
| 10 | Max. Discharge Current | 35A | 0.9C |
| 11 | Burst Discharge Current | 100A | ≤3ms |
| 12 | Charge Temperature | 19.6V | 2.8V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~+45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~+60°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ +45°C | ≤3 months |
| -20°C~ +25°C | ≤1 Year | ||
| 17 | Weight | About 3.5 | kg |
25.2V 40Ah 21700 battery pack FAQs
Our device has limited space. Can the battery size or connector be changed?
Yes. We can customize dimensions, connector types (XT90, Anderson, aviation plugs), and cable lengths to fit your equipment perfectly.
Will performance drop in extreme temperatures, like underwater or marine environments?
Our 21700 cells work well between -20°C and +60°C. The pack delivers about 80% capacity at -20°C. We can also provide options for low- or high-temperature conditions.
Is there a higher protection level than IP68?
IP68 is great for long-term underwater use. If needed, we can add salt spray resistance, anti-corrosion coating, and vibration protection for harsher conditions
Which certifications are available? Can it be exported?
We can provide UN38.3, MSDS, CE, UL, RoHS and other certifications or reports as needed for international shipping and market compliance.
What is the charging method? Does it need a special charger?
The pack supports standard CC/CV charging. We recommend a charger with 29.4V output and ≤20A. We can supply compatible chargers if necessary.
