24V 18650 Li-ion Battery Pack
CMB is focusing on designing 24V 18650 battery packs with reliable quality. The 24V lithium battery is made of the world’s most reliable brand cells to meet your needs. The nominal voltage of the 18650 battery 24V is 25.2V or 25.9V. The 24V battery pack 18650 from CM Batteries is made with the depth test of the electronic performance.
CMB has a team of experienced engineers who can design and test batteries to meet your specific requirements. When you are looking for a custom 24V 18650 battery pack, please do not hesitate to contact us.
The Features of the 24V 18650 Battery Pack
- The full charge voltage is 29.4V.
- Integrated BMS with over-discharge, overcharge, and short circuit protection.
- Spare parts options: connector/LED display
Request a Quote
Custom 24V 18650 Li-ion Battery Pack Solutions
To learn more about our 7s 18650 battery pack solutions, click on the item titles below.
Detail:
- Made of 6pcs Samsung 25R cells
- Integrated BMS for 40A discharge current
- Application for power tool, LED light
24V 5Ah 18650 7S2P Battery Pack Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 25.2V | 3.6V/Cell |
| 2 | Nominal Capacity | 5Ah | @0.2C |
| 3 | Minimum Capacity | 4.9Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤180mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 29.4V | 4.2V/Cell |
| 7 | Standard Charge Current | 2.5A | @0.5C |
| 8 | Max. Charge Current | 5A | BMS Limit |
| 9 | Standard Discharge Current | 20A | / |
| 10 | Max. Discharge Current | 44A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 17.5V | 2.5V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~70°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 720g | / |
| 18 | Special Request | / | / |
Detail:
- Made of 28 pcs ICR18650 2600mAh cells
- Application for coffee machine, electric bike
- The nominal voltage is 25.2V
24V 10Ah 18650 7S4P Battery Pack Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 25.9V | 3.7V/Cell |
| 2 | Nominal Capacity | 10.4Ah | @0.2C |
| 3 | Minimum Capacity | 10Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 29.4V | 4.2V/Cell |
| 7 | Standard Charge Current | 2A | @0.2C |
| 8 | Max. Charge Current | 5A | BMS Limit |
| 9 | Standard Discharge Current | 10A | / |
| 10 | Max. Discharge Current | 15A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 19.25V | 2.75V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~70°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 1.45kg | / |
| 18 | Special Request | / | / |
Detail:
- The battery is made of 42pcs brand 18650 2600mAh cells
- Application for electric golf trolley and cleaning equipment
- SMBus BMS solution
24V 15Ah 18650 7S6P Battery Pack Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 25.9V | 3.7V/Cell |
| 2 | Nominal Capacity | 15.6Ah | @0.2C |
| 3 | Minimum Capacity | 15Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 29.4V | 4.2V/Cell |
| 7 | Standard Charge Current | 3.12A | @0.2C |
| 8 | Max. Charge Current | 8A | BMS Limit |
| 9 | Standard Discharge Current | 15A | / |
| 10 | Max. Discharge Current | 20A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 19.25V | 2.75V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~70°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 2.3kg | / |
| 18 | Special Request | / | / |
Detail:
- Made of 49pcs 18650 2900mAh cells
- Application for electric wheelchair and outdoor camera
- 7 series 20A discharge current BMS
24V 20.3Ah 18650 7S7P Battery Pack Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 25.9V | 3.7V/Cell |
| 2 | Nominal Capacity | 20.3Ah | @0.2C |
| 3 | Minimum Capacity | 20Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 29.4V | 4.2V/Cell |
| 7 | Standard Charge Current | 4.06A | @0.2C |
| 8 | Max. Charge Current | 10A | BMS Limit |
| 9 | Standard Discharge Current | 20A | / |
| 10 | Max. Discharge Current | 25A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 19.25V | 2.75V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~70°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 2.6kg | / |
| 18 | Special Request | / | / |
Detail:
- Made of 105pcs BAK 3350mAh 18650 cells
- Application for forklift and motorcycle
- SMBus BMS solution
24V 50Ah 18650 7S15P Battery Pack Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 25.9V | 3.7V/Cell |
| 2 | Nominal Capacity | 50.25Ah | @0.2C |
| 3 | Minimum Capacity | 49.5Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 29.4V | 4.2V/Cell |
| 7 | Standard Charge Current | 10.05A | @0.2C |
| 8 | Max. Charge Current | 25A | BMS Limit |
| 9 | Standard Discharge Current | 50A | / |
| 10 | Max. Discharge Current | 60A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 19.25V | 2.75V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~70°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 5.3kg | / |
| 18 | Special Request | / | / |
- 24V 5Ah Batteries
-
Detail:
- Made of 6pcs Samsung 25R cells
- Integrated BMS for 40A discharge current
- Application for power tool, LED light
24V 5Ah 18650 7S2P Battery Pack Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 25.2V 3.6V/Cell 2 Nominal Capacity 5Ah @0.2C 3 Minimum Capacity 4.9Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤180mΩ AC 1KHZ 6 Standard Charge Voltage 29.4V 4.2V/Cell 7 Standard Charge Current 2.5A @0.5C 8 Max. Charge Current 5A BMS Limit 9 Standard Discharge Current 20A / 10 Max. Discharge Current 44A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 17.5V 2.5V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~70°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 720g / 18 Special Request / / - 24V 10Ah Batteries
-
Detail:
- Made of 28 pcs ICR18650 2600mAh cells
- Application for coffee machine, electric bike
- The nominal voltage is 25.2V
24V 10Ah 18650 7S4P Battery Pack Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 25.9V 3.7V/Cell 2 Nominal Capacity 10.4Ah @0.2C 3 Minimum Capacity 10Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤200mΩ AC 1KHZ 6 Standard Charge Voltage 29.4V 4.2V/Cell 7 Standard Charge Current 2A @0.2C 8 Max. Charge Current 5A BMS Limit 9 Standard Discharge Current 10A / 10 Max. Discharge Current 15A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 19.25V 2.75V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~70°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 1.45kg / 18 Special Request / / - 24V 15Ah Batteries
-
Detail:
- The battery is made of 42pcs brand 18650 2600mAh cells
- Application for electric golf trolley and cleaning equipment
- SMBus BMS solution
24V 15Ah 18650 7S6P Battery Pack Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 25.9V 3.7V/Cell 2 Nominal Capacity 15.6Ah @0.2C 3 Minimum Capacity 15Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤200mΩ AC 1KHZ 6 Standard Charge Voltage 29.4V 4.2V/Cell 7 Standard Charge Current 3.12A @0.2C 8 Max. Charge Current 8A BMS Limit 9 Standard Discharge Current 15A / 10 Max. Discharge Current 20A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 19.25V 2.75V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~70°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 2.3kg / 18 Special Request / / - 24V 20.3Ah Batteries
-
Detail:
- Made of 49pcs 18650 2900mAh cells
- Application for electric wheelchair and outdoor camera
- 7 series 20A discharge current BMS
24V 20.3Ah 18650 7S7P Battery Pack Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 25.9V 3.7V/Cell 2 Nominal Capacity 20.3Ah @0.2C 3 Minimum Capacity 20Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤200mΩ AC 1KHZ 6 Standard Charge Voltage 29.4V 4.2V/Cell 7 Standard Charge Current 4.06A @0.2C 8 Max. Charge Current 10A BMS Limit 9 Standard Discharge Current 20A / 10 Max. Discharge Current 25A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 19.25V 2.75V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~70°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 2.6kg / 18 Special Request / / - 24V 50Ah Batteries
-
Detail:
- Made of 105pcs BAK 3350mAh 18650 cells
- Application for forklift and motorcycle
- SMBus BMS solution
24V 50Ah 18650 7S15P Battery Pack Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 25.9V 3.7V/Cell 2 Nominal Capacity 50.25Ah @0.2C 3 Minimum Capacity 49.5Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤200mΩ AC 1KHZ 6 Standard Charge Voltage 29.4V 4.2V/Cell 7 Standard Charge Current 10.05A @0.2C 8 Max. Charge Current 25A BMS Limit 9 Standard Discharge Current 50A / 10 Max. Discharge Current 60A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 19.25V 2.75V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~70°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 5.3kg / 18 Special Request / /
More Technical Articles on 18650 Battery Pack
24V 7s 18650 Battery Pack FAQ
Does CMB provide custom 24V 18650 li ion battery packs?
Of course, we can design 24V 18650 li-ion battery packs for your needs.
What kinds of brand cells are assembled into 24V lithium ion battery packs?
We will assemble your 24V lithium-ion battery packs with the specific brand cells that are compatible with your needs. We have Samsung, Panasonic, LG, BAK, Molicell, etc famous brand cells.
What is the MOQ for 24V 18650 li ion battery pack?
The MOQ is 200pcs.
Can we use the standard li ion charger for 24V 18650 li ion battery pack?
Please charge the battery with the dedicated 24V lithium battery from the 18650 battery manufacturer.
