36V 18650 Li-ion Battery Pack
CMB manufactures various 36V 18650 battery packs for industrial applications. Each 36V 18650 battery pack is packed with customized battery holders to ensure their stability and efficiency. Our 18650 10S 36V battery packs are utilized for 36V e-bike batteries and cleaning equipment but are not limited to boats, water monitor systems, and farm robots. Engineered for versatility, performance, and reliability, our custom solutions are driving the future of e-mobility and smart industrial systems.
The Features of the 36V 18650 Li-ion Battery Pack
- Top-Quality Cells: We only use cells from the world’s most reliable brands such as Samsung, LG, Panasonic, Molicell, BAK, and DMEC.
- Advanced Battery Management System (BMS): Our custom 36V battery packs come with an intelligent BMS that ensures optimal performance and safety. The BMS includes protection against over-discharge, overcharge, and short circuits. Smart BMS options with UART, RS485, and CANBUS protocols are available for enhanced communication and control.
- Comprehensive certification support: UN 38.3, IEC 62133, UL 2054, MSDS.
- Expertise and Proven Track Record: With over 10 years of experience and numerous successful customization projects, our team brings extensive expertise to every custom battery solution.
- Custom Solutions: Tailored solutions for size, shell design, and capacity, powering e-bikes, cleaning equipment, boats, water monitoring systems, farm robots, and more.
Request a Quote
Custom 36V 18650 Li-ion Battery Pack Solutions
To learn more about our 10s 18650 battery pack solutions, click on the item titles below.
Detail:
- Made of 30pcs 18650 BAK 3350mAh cells
- Overdischarge and overcharge protection
- Application for electric bikes and portable devices
36V 10Ah 18650 10S3P Li-ion Battery Pack Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 36V | 3.6V/Cell |
| 2 | Nominal Capacity | 10Ah | @0.2C |
| 3 | Minimum Capacity | 9.75Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 42V | 4.2V/Cell |
| 7 | Standard Charge Current | 2A | @0.2C |
| 8 | Max. Charge Current | 5A | BMS Limit |
| 9 | Standard Discharge Current | 15A | / |
| 10 | Max. Discharge Current | 30A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 25V | 2.5V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~60°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 1.65kg | / |
| 18 | Special Request | / | / |
Detail:
- Made of 40pcs Samsung 18650 35E cells
- Integrated BMS
- Shapes and dimensions are customized to your needs
36V 14Ah 18650 10S4P Li-ion Battery Pack Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 36V | 3.6V/Cell |
| 2 | Nominal Capacity | 14Ah | @0.2C |
| 3 | Minimum Capacity | 13.8Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 42V | 4.2V/Cell |
| 7 | Standard Charge Current | 2.8A | @0.2C |
| 8 | Max. Charge Current | 7A | BMS Limit |
| 9 | Standard Discharge Current | 14A | / |
| 10 | Max. Discharge Current | 20A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 27V | 2.7V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~60°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 2.15kg | / |
| 18 | Special Request | / | / |
Detail:
- The battery is made of 70pcs famous brand 18650 2900mAh cells
- With good insulation and heat radiation function
- SOC management
36V 20Ah 18650 10S7P Li-ion Battery Pack Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 37V | 3.7V/Cell |
| 2 | Nominal Capacity | 20.3Ah | @0.2C |
| 3 | Minimum Capacity | 19.25Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 42V | 4.2V/Cell |
| 7 | Standard Charge Current | 4.06A | @0.2C |
| 8 | Max. Charge Current | 10A | BMS Limit |
| 9 | Standard Discharge Current | 20A | / |
| 10 | Max. Discharge Current | 40A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 27.5V | 2.75V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~60°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 3.8kg | / |
| 18 | Special Request | / | / |
- 36V 10Ah 10S3P Battery Pack
-
Detail:
- Made of 30pcs 18650 BAK 3350mAh cells
- Overdischarge and overcharge protection
- Application for electric bikes and portable devices
36V 10Ah 18650 10S3P Li-ion Battery Pack Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 36V 3.6V/Cell 2 Nominal Capacity 10Ah @0.2C 3 Minimum Capacity 9.75Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤200mΩ AC 1KHZ 6 Standard Charge Voltage 42V 4.2V/Cell 7 Standard Charge Current 2A @0.2C 8 Max. Charge Current 5A BMS Limit 9 Standard Discharge Current 15A / 10 Max. Discharge Current 30A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 25V 2.5V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~60°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 1.65kg / 18 Special Request / / - 36V 14Ah 10S4P Battery Pack
-
Detail:
- Made of 40pcs Samsung 18650 35E cells
- Integrated BMS
- Shapes and dimensions are customized to your needs
36V 14Ah 18650 10S4P Li-ion Battery Pack Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 36V 3.6V/Cell 2 Nominal Capacity 14Ah @0.2C 3 Minimum Capacity 13.8Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤200mΩ AC 1KHZ 6 Standard Charge Voltage 42V 4.2V/Cell 7 Standard Charge Current 2.8A @0.2C 8 Max. Charge Current 7A BMS Limit 9 Standard Discharge Current 14A / 10 Max. Discharge Current 20A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 27V 2.7V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~60°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 2.15kg / 18 Special Request / / - 36V 20Ah 10S7P Battery Pack
-
Detail:
- The battery is made of 70pcs famous brand 18650 2900mAh cells
- With good insulation and heat radiation function
- SOC management
36V 20Ah 18650 10S7P Li-ion Battery Pack Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 37V 3.7V/Cell 2 Nominal Capacity 20.3Ah @0.2C 3 Minimum Capacity 19.25Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤200mΩ AC 1KHZ 6 Standard Charge Voltage 42V 4.2V/Cell 7 Standard Charge Current 4.06A @0.2C 8 Max. Charge Current 10A BMS Limit 9 Standard Discharge Current 20A / 10 Max. Discharge Current 40A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 27.5V 2.75V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~60°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 3.8kg / 18 Special Request / /
More Technical Articles on 18650 Battery Pack
36V 10S 18650 Battery Pack FAQ
Does CMB provide custom 36V 18650 li ion battery packs?
Of course, we can design 36V 18650 li-ion battery packs for your needs.
What kinds of brand cells are assemblied into 36V lithium ion battery packs?
We will assemble your 36V lithium-ion battery packs with the specific brand cells that are compatible with your needs. We have Samsung, Panasonic, LG, BAK, Molicell, etc famous brand cells.
What is the MOQ for 36V 18650 li ion battery pack?
The MOQ is 200pcs.
Can we use the standard li ion charger for 36V 18650 li ion battery pack?
Please charge the battery with the dedicated 36V lithium battery from the 18650 battery manufacturer.
