Product Highlights
- The 48V 20Ah electric bike battery with 21700 cells is more powerful than hailong 48V 17.5Ah 18650 e-bike battery.
- CMB customizes nickel plate, battery holder, and BMS for 48V 21700 e-bike battery to offer reliable and long-lasting quality.
- Our hailong battery can hold 52pcs 21700 li ion cells.
- The dimension is 90*109*362 (mm)
- The weight: About 5KG
48V 20Ah 21700 Lithium Ion Battery for Electric Bike Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 46.8V | 3.6V/Cell |
| 2 | Nominal Capacity | 20Ah | @0.2C |
| 3 | Minimum Capacity | 19.6Ah | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤180mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 54.6V | 4.2V/Cell |
| 7 | Standard Charge Current | 9.8A | @0.2C |
| 8 | Max. Charge Current | 20A | BMS Limit |
| 9 | Standard Discharge Current | 3.92A | @0.2C |
| 10 | Max. Discharge Current | 40A | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 32.5V | 2.5V/Cell |
| 13 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~70°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 17 | Weight | About 5Kg | / |
| 18 | Special Request | / | / |
The Development Timeline Schedule of Custom Battery Pack for Ebike
Primary Solution
We’ll provide you with the primary solution within 2 days once we get your questionnaire.
Drawing Release
We’ll provide the first version of the CAD drawing within 2 days.
Specification Approval
We’ll provide you with the specifications to get the approval within 2 days.
Estimation
We’ll provide an estimation for you to approve within 1 day.
Tooling
We’ll need 8-9 weeks to open the tooling for you if your custom 21700 battery pack for electric bikes needs the customized housing.
BMS Development
We’ll need to make the BMS development within 7-10 days and customized smart BMS development takes 25-30 days.
Sample Release
We’ll need 5 days to make the new sample production before release.
The Sample Shipping Time
We’ll need 4-7 days to ship the sample by UPS.
Certificates
You can get your 21700 battery packs for your electric bike with 2-3weeks expected the UL certificate.
- Parameter Specifications
-
48V 20Ah 21700 Lithium Ion Battery for Electric Bike Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 46.8V 3.6V/Cell 2 Nominal Capacity 20Ah @0.2C 3 Minimum Capacity 19.6Ah / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤180mΩ AC 1KHZ 6 Standard Charge Voltage 54.6V 4.2V/Cell 7 Standard Charge Current 9.8A @0.2C 8 Max. Charge Current 20A BMS Limit 9 Standard Discharge Current 3.92A @0.2C 10 Max. Discharge Current 40A / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 32.5V 2.5V/Cell 13 Cycle Life ≥500 cycles Retention: ≥80% 14 Charge Temperature 0°C~45°C Standard Charge 15 Discharge Temperature -20°C ~70°C Standard Discharge 16 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 17 Weight About 5Kg / 18 Special Request / / - Development Timeline Schedule
-
The Development Timeline Schedule of Custom Battery Pack for Ebike
You can get in contact with our consultant to get the specific timeline for your custom battery pack solution.Primary Solution
We’ll provide you with the primary solution within 2 days once we get your questionnaire.
Drawing Release
We’ll provide the first version of the CAD drawing within 2 days.
Specification Approval
We’ll provide you with the specifications to get the approval within 2 days.
Estimation
We’ll provide an estimation for you to approve within 1 day.
Tooling
We’ll need 8-9 weeks to open the tooling for you if your custom 21700 battery pack for electric bikes needs the customized housing.
BMS Development
We’ll need to make the BMS development within 7-10 days and customized smart BMS development takes 25-30 days.
Sample Release
We’ll need 5 days to make the new sample production before release.
The Sample Shipping Time
We’ll need 4-7 days to ship the sample by UPS.
Certificates
You can get your 21700 battery packs for your electric bike with 2-3weeks expected the UL certificate.
Related Battery Pack Solutions
More Technical Articles on 21700 Battery Pack
48V 20Ah 21700 Electric Bike Battery FAQ
Do you provide the extra battery models for the 48V 20Ah 21700 electric bike battery?
Of course, we can provide the standard battery case for the 48V 20Ah 21700 electric bike battery and design a unique one.
What is your MOQ for 48V 20Ah 21700 electric bike battery?
We do not have the MOQ request for the sample order and the MOQ for bulk production is 10pcs for each model.
Can provide hailong type for ebike battery with 21700 cells?
Yes, we have some hailong battery types for your options with 21700 cells.
