36V 15Ah 21700 Battery Pack for Electric Bike
CM Batteries has been one pioneer in manufacturing electric bike batteries for over 15 years. We are dedicated to custom energy solutions for electric motorcycles with innovation, reliable quality, and high performance. One of our B2B customers required a high-capacity, lightweight battery integrated into his custom e-bike model without compromising performance or safety. Our engineering team designed a 36V 15Ah 21700 ebike battery pack with the perfect blend of power, convenience, and versatility.
36V 15Ah Ebike Battery Customization Solution
Features:
- Description: 36v 15ah ebike battery pack made of 21700 cells, with a 10S3P configuration. Also, providing a designated 42V 2A charger and is compatible with bike motors ranging from 200W to 500W.
- Scopes of Application: It can be used for 36V electric bicycles, electric unicycles, electric scooters, electric tricycles, electric wheelchair, adult electric bicycles, etc.
- Custom battery processes: First, provide the voltage, capacity, desired dimension, motor power, and other parameters you require. Next step, we’ll design one custom battery pack to your needs. If your battery pack design is more complex, your consultant will arrange the video meeting and invite our engineering team to join the meeting together.
- Advanced BMS: Integrated a High-Performance 30A BMS protection board for enhanced safety from short-circuit, over-current, over-charge, and over-discharge damages.
- Versatile Temperature Range: Operate efficiently in harsh weather conditions, from -20°C to 60°C.
36V 15Ah Lithium Ion Battery Parameter
| No. | Parameter | Specification |
|---|---|---|
| 1 | Rated Capacity | 15Ah |
| 2 | Rated Voltage | 36V |
| 3 | Cell Source Resistance | 20mΩ |
| 4 | Cell Type | 3.7V 5Ah / 21700 cell |
| 5 | Cell Configuration | 3-parallel 10-series (30 cells total) |
| 6 | Battery Dimensions | 75 x 75 x 225mm |
| 7 | Weight | 2.7kg |
| 8 | Discharge voltage | 30V ± 1V |
| 9 | Load voltage | 42V |
| 10 | Rated discharge current | 25A |
| 11 | Maximum instantaneous discharge current | 70A |
| 12 | Maximum continuous discharge current | 25A |
| 13 | Standard load current | 2A |
| 14 | Charging Time (with standard current) | about 5-7 h |
| 15 | Charging Temperature Range | 0°C to 45°C |
| 16 | Discharging Temperature Range | -20°C to 60°C |
Related Battery Pack Cases
48V 20Ah 21700 Battery Pack for Electric Bike
36V 11.6Ah Integrated Battery for Electric Bike
36V 11.6Ah Rear Rack Battery for Electric Bike
36V 14.5Ah Sliver Fish E-bike Battery
36V 15Ah Ebike Battery FAQs
Is there a warranty on this battery?
Yes, we offer a 12-month warranty against manufacturing defects. Extended servie is available to offer.
Is there a way to monitor the battery's performance?
Yes, many of our e-bike batteries come with smart features including Bluetooth, SOC, SOH if needed.
What’s your MOQ?
We will provide samples for testing without MOQ limit.
What are the general certifications for e-bike batteries?
Some models of our 36V ebike batteries are verified with certifications UN38.3 and CE.
Can I use a different charger with this battery?
We recommend the dedicated charger or an official replacement. Using incompatible chargers may damage the battery.
