48V 10Ah 480Wh Integrated Ebike Lithium Ion Battery Pack
In the e-bike industry, we understand the importance of high-quality battery solutions to enhance the competitiveness of bikes. As a leading e-bike battery manufacturer, we have designed this frame-integrated integrated ebike battery 48v 10ah for our customers, which offers a perfect combination of performance, safety, and design integration to provide significant advantages for e-bikes.
48v 10Ah Lithium Ion Battery Customization Solution
- Integrated Design: Compact design allows for effortless incorporation into our bike frames, significantly enhancing the overall aesthetics of e-bikes. The black hard plastic shell protects the battery and the LED level indicator clue the battery SOC.
- High Capacity: 480Wh power capacity for extended range.
- Premium Cells: Samsung 35E 18650 3500mAh 3C discharge rate cell.
- Advanced BMS: Incorporates a high-performance BMS with 30A continuous discharge current with enhanced safety against short-circuit, over-current, over-charge, and over-discharge.
- Versatile Temperature Range: Operates efficiently in various weather conditions, from -20°C to 60°C for discharging.
- Extended Warranty: 24-month warranty for peace of mind.
Our 48v 10ah lithium battery pack has the compact shape, assemblying easily into bike frames and improving the apperance and performance. We provide the best-integrated battery solution and customization options to match your e-bike style.
48V 10Ah E-Bike Battery Parameter
| No. | Parameter | Specification |
|---|---|---|
| 1 | Rated Capacity | 10Ah |
| 2 | Rated Voltage | 48V |
| 3 | Power Energy | 480Wh |
| 4 | Composed Type | 13S4P |
| 5 | Battery BMS | 30A BMS |
| 6 | Max. Charge Voltage | 54.6V |
| 7 | Discharge Cut-off Voltage | 39V |
| 8 | Max. Charge Current | 5A |
| 9 | Net Weight | Approx 3.6kg |
| 10 | Battery Dimensions | 430*45*108mm |
| 11 | Charging Temperature Range | 0°C to 45°C |
| 12 | Discharging Temperature Range | -20°C to 60°C |
| 13 | Cycle Life | More than 500 times |
Related Battery Pack Cases
48V 11.6Ah 556.8Wh Integrated Lithium Ebike Battery
48v 20ah Lithium Battery for Integrated Ebike
52V 20Ah 1040Wh Integrated Ebike Battery
36V 20Ah 720Wh Integrated Ebike Battery Pack
48V 10Ah Lithium-ion Battery for Electric Bike FAQs
What type of cells are used in this battery?
Our batteries typically use premium cells from manufacturers like DMEGC or Samsung, such as the INR 18650-29E cells but it depends on your specific needs.
Do you provide the else battery packs for the 48V electric bike?
The 48V 14Ah pack is an excellent standard option but CM Batteries specializes in customizing battery solutions to meet your specific needs.
Is there a way to monitor the battery's performance?
Yes, some of our e-bike batteries come with smart features including Bluetooth,SOC,SOH if needed.
What’s your MOQ?
We will provide samples for testing without MOQ limit.
What are the general certifications for e-bike batteries?
Some models of our 48V ebike batteries are verified with certifications UN38.3 and CE.
Is there a warranty on this battery?
Yes, we offer a 24-month warranty.
Can I use a different charger with this battery?
We recommend the dedicated charger or an official replacement. Using incompatible chargers may damage the battery.
