52V 20Ah 1040Wh Integrated Lithium-ion Ebike Battery
As e-bike battery experts, our 52V 20Ah ebike battery is an e-bike power solution with high-performance . That gives a full capabilities for manufacturers who looking for premium battery options for high-power e-bikes.
52V 20Ah Ebike Battery Customization Solution
- Cell Configuration: 14S4P arrangement using Samsung 21700 50S cells.
- High Capacity: 1040Wh power delivery makes this unit ideal for premium e-bike models.
- Advanced BMS: Incorporates a high-performance BMS with 60A continuous discharge current with enhanced safety against short-circuit, over-current, over-charge, and over-discharge.
- Versatile Temperature Range: Operates efficiently in various weather conditions, from -20°C to 60°C for discharging.
- Applications: Built for high-power applications and long rides.
- Extended Warranty: 24-month warranty for peace of mind.
We can provide the best-integrated 52V 20Ah ebike battery solution and customization options to match your e-bike style.
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 50.4V | 3.6V/Cell |
| 2 | Nominal Capacity | 20Ah | @0.2C |
| 3 | Minimum Capacity | 19.3Ah | |
| 4 | Shipment Voltage | / | |
| 5 | Initial Internal Impedance | ≤130mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 58.8V | 4.2V/Cell |
| 7 | Standard Charge Current | 4A | @0.2C |
| 8 | Max. Charge Current | 10A | |
| 9 | Standard Discharge Current | 4A | @0.2C |
| 10 | Max. Discharge Current | 60A | |
| 11 | Burst Discharge Current | 90±10A | ≤100ms |
| 12 | Discharge Cut-off Voltage | 37.8V | 2.7V/Cell |
| 13 | Cycle Life | ≥350cycles | Retention: ≥70% |
| 14 | Charge Temperature | 0°C~45°C | Standard Charge |
| 15 | Discharge Temperature | -20°C ~+60°C | Standard Discharge |
| 16 | Storage Temperature | -20°C~ +45°C | ≤3 Months |
| -20°C~25°C | ≤1 Year | ||
| 17 | Weight | About 4.3 | kg |
| 18 | Special Request |
Related Battery Pack Cases
48V 11.6Ah 556.8Wh Integrated Lithium Ebike Battery
43.2V 40Ah 21700 Electric Surfboard Battery Packs
48v 20ah Lithium Battery for Integrated Ebike
36V 20Ah 720Wh Integrated Ebike Battery Pack
52V 20Ah Lithium-ion Battery for Electric Bike FAQs
How long will a 52V 20Ah battery last?
The 52V 20Ah battery would last for approximately 4 hours.
How far can a 52V 20Ah battery go?
It is 52V x 20Ah =1014 Watt Hour, 1014 Watt Hour ÷ 16 Watt Hour = 65 miles.
What type of cells are used in this battery?
Our batteries typically use premium cells from manufacturers like DMEGC or Samsung, such as the INR 18650-29E cells but it depends on your specific needs.
Is there a way to monitor the battery's performance?
Yes, many of our e-bike batteries come with smart features including Bluetooth,SOC,SOH if needed.
What’s your MOQ?
We will provide samples for testing without MOQ limit.
What are the general certifications for e-bike batteries?
Some models of our 52V ebike batteries are verified with certifications UN38.3 and CE.
Can I use a different charger with this battery?
We recommend the dedicated charger or an official replacement. Using incompatible chargers may damage the battery.
