6.4V 18Ah LiFePO4 Battery Pack
This 6.4V 18Ah 2S3P LiFePO4 battery pack is made with high-quality 32700 cells and is designed to handle 10A of continuous discharge. It is perfect for long-lasting power in solar lighting, surveillance cameras, and portable audio systems. It is made to replace standard SLA batteries and has a longer cycle life, a stable output, and a small footprint. This makes it the perfect choice for OEMs who need custom-fit, maintenance-free energy storage.
Key features：
- Made of 6 pcs 32700 LFP cells
- Applications for solar lighting, cameras, amplifiers, etc.
- Supports 10A continuous discharge, overcharge/discharge, temp protection
- XT30 / DC / JST / Customized plug (as per device needs)
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 6.4V | 3.2V/Cell |
| 2 | Nominal Capacity | 18Ah | @0.2C |
| 3 | Minimum Capacity | 17.8Ah | |
| 4 | Shipment Voltage | / | |
| 5 | Initial Internal Impedance | ≤100mΩ | AC 1KHZ |
| 6 | Standard Charge Voltage | 7.3V | 3.65V/Cell |
| 7 | Standard Charge Current | 3.6A | @0.2C |
| 8 | Max. Charge Current | 9A | |
| 9 | Standard Discharge Current | 3.6A | @0.2C |
| 10 | Max. Discharge Current | 10A | |
| 11 | Burst Discharge Current | 30A | ≤500ms |
| 12 | Discharge Cut-off Voltage | 5V | 2.5V/Cell |
| 13 | Cycle Life | ≥1500cycles | Retention: ≥80% |
| 14 | Charge Temperature | 0°C~+60°C | Standard Charge |
| 15 | Discharge Temperature | -10°C ~+60°C | Standard Discharge |
| 16 | Storage Temperature | 0°C~ +35°C | ≤3 months |
| 0°C~ +25°C | ≤1 Year | ||
| 17 | Weight | About 0.9 | kg |
6.4V 18Ah 32700 Battery Pack FAQs
What’s the maximum discharge current? Is there a peak current rating?
The battery supports a continuous discharge current of up to 10A, and it can handle peak currents up to 15A for short durations (<10 seconds). This makes it suitable for devices requiring stable power like amplifiers and surveillance systems.
Can it be used in cold or high-temperature environments?
Yes. The standard operating temperature range is -4°F to 140°F (-20°C to 60°C).
For extreme cold environments, we also offer low-temperature versions that operate down to -22°F (-30°C), suitable for winter, forest, or high-altitude deployments.
Can I customize the pack for my device?
Yes. We support customization of wiring, connectors, casing, communication interface, and mounting structure to fit your system requirements. Contact our engineering team for OEM/ODM collaboration.
Do you provide testing and certification services?
CM Batteries can help with certifications like UN38.3, IEC62133, and others. Testing reports and MSDS are also accessible.
Do you support low-volume prototyping or batch orders?
Yes, we offer small-batch prototyping and can scale production to support your company’s project needs, whether you’re testing or ready for mass production.
