High Temperature LiPo Battery
CMB’s high temperature LiPo batteries are tailored to outdoor sensors or camera systems, discharge at 0°C~80°C and charge at 0°C~45°C.
The dedicated engineering team at CMB is committed to enhancing the performance of high-temperature LiPo rechargeable batteries. With a focus on innovation and technology, we’ve developed battery packs with unmatched features, including high density and high discharge power specifically tailored for high-temperature environments.
At CMB, we understand that every application is unique. That’s why we offer custom high-temperature LiPo battery solutions tailored to your specific requirements. Our experienced team is ready to work with you to design and deliver the perfect battery solution for your outdoor sensors or IoT devices. Please contact us.
Custom High Temperature LiPo Battery Solutions
Details:
- Made of 2pcs 3.7V 3600mAh high temperature LiPo cells
- Dimension :17*55*65.5 (mm)
- Application for outdoor IOT devices
- Discharge at 1.5A 80°C
1S2P 3.7V 7200mAh High Temperature LiPo Battery Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 3.7V | 3.2V/Cell |
| 2 | Nominal Capacity | 7200mAh | @0.2C |
| 3 | Minimum Capacity | 7200mAh | / |
| 4 | Shipment Voltage | / | / |
| 5 | Initial Internal Impedance | ≤120mΩ | 3.7V AC 1KHz measured |
| 6 | Standard Charge Voltage | 4.2V | 4.2V/Cell |
| 7 | Standard Charge Current | 1440mA | @0.2C |
| 8 | Max. Charge Current | 1440mA | BMS Limit |
| 9 | Standard Discharge Current | 1440mA | @0.2C |
| 10 | Max. Discharge Current | 1440mA | / |
| 11 | Burst Discharge Current | / | / |
| 12 | Discharge Cut-off Voltage | 2.4V | 2.4V/Cell |
| 13 | Cycle Life | ≥300 cycles | Retention: ≥80% |
| 14 | Charge Temperature | 10°C~45°C | Standard Charge |
| 15 | Discharge Temperature | 0°C ~80°C | Standard Discharge |
| 16 | Storage Temperature | -10°C~ 45°C | ≤3 Months |
| 15°C ~ 35°C | ≤1 Year | ||
| 17 | Weight | About 0.126kg | / |
| 18 | Special Request | / | / |
Click for Details
Details:
- Application outdoor monitor system
- Discharge capabilities ranging from -10°C to +70°C
- One year warranty
2S 7.4V 750mAh High Temperature LiPo Battery Parameter Specifications
| No. | Item | Parameter | Remark |
|---|---|---|---|
| 1 | Nominal Voltage | 7.4V | 3.2V/Cell |
| 2 | Nominal Capacity | 0.75Ah | @0.2C |
| 3 | Minimum Capacity | 0.75Ah | / |
| 4 | Initial Internal Impedance | ≤250mΩ | 3.7V AC 1KHz measured |
| 5 | Standard Charge Voltage | 8.4V | 4.2V/Cell |
| 6 | Standard Charge Current | 0.15A | @0.2C |
| 7 | Max. Charge Current | 0.75A | BMS Limit |
| 8 | Standard Discharge Current | 0.15A | @0.2C |
| 9 | Max. Discharge Current | 2A | / |
| 10 | Burst Discharge Current | 2.5-3A | ≤15ms |
| 11 | Discharge Cut-off Voltage | 4.8V | 2.4V/Cell |
| 12 | Cycle Life | ≥300 cycles | Retention: ≥60% |
| 13 | Charge Temperature | 0°C~45°C | Standard Charge |
| 14 | Discharge Temperature | -10°C ~70°C | Standard Discharge |
| 15 | Storage Temperature | -20°C~ 35°C | ≤3 Months |
| 0°C ~ 30°C | ≤1 Year | ||
| 16 | Weight | About 0.025kg | / |
Click for Details
- 1S2P 3.7V 7200mAh LiPo Battery
-
Details:
- Made of 2pcs 3.7V 3600mAh high temperature LiPo cells
- Dimension :17*55*65.5 (mm)
- Application for outdoor IOT devices
- Discharge at 1.5A 80°C
1S2P 3.7V 7200mAh High Temperature LiPo Battery Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 3.7V 3.2V/Cell 2 Nominal Capacity 7200mAh @0.2C 3 Minimum Capacity 7200mAh / 4 Shipment Voltage / / 5 Initial Internal Impedance ≤120mΩ 3.7V AC 1KHz measured 6 Standard Charge Voltage 4.2V 4.2V/Cell 7 Standard Charge Current 1440mA @0.2C 8 Max. Charge Current 1440mA BMS Limit 9 Standard Discharge Current 1440mA @0.2C 10 Max. Discharge Current 1440mA / 11 Burst Discharge Current / / 12 Discharge Cut-off Voltage 2.4V 2.4V/Cell 13 Cycle Life ≥300 cycles Retention: ≥80% 14 Charge Temperature 10°C~45°C Standard Charge 15 Discharge Temperature 0°C ~80°C Standard Discharge 16 Storage Temperature -10°C~ 45°C ≤3 Months 15°C ~ 35°C ≤1 Year 17 Weight About 0.126kg / 18 Special Request / / Click for Details
- 2S 7.4V 750mAh LiPo Battery
-
Details:
- Application outdoor monitor system
- Discharge capabilities ranging from -10°C to +70°C
- One year warranty
2S 7.4V 750mAh High Temperature LiPo Battery Parameter Specifications
No. Item Parameter Remark 1 Nominal Voltage 7.4V 3.2V/Cell 2 Nominal Capacity 0.75Ah @0.2C 3 Minimum Capacity 0.75Ah / 4 Initial Internal Impedance ≤250mΩ 3.7V AC 1KHz measured 5 Standard Charge Voltage 8.4V 4.2V/Cell 6 Standard Charge Current 0.15A @0.2C 7 Max. Charge Current 0.75A BMS Limit 8 Standard Discharge Current 0.15A @0.2C 9 Max. Discharge Current 2A / 10 Burst Discharge Current 2.5-3A ≤15ms 11 Discharge Cut-off Voltage 4.8V 2.4V/Cell 12 Cycle Life ≥300 cycles Retention: ≥60% 13 Charge Temperature 0°C~45°C Standard Charge 14 Discharge Temperature -10°C ~70°C Standard Discharge 15 Storage Temperature -20°C~ 35°C ≤3 Months 0°C ~ 30°C ≤1 Year 16 Weight About 0.025kg / Click for Details
A Comprehensive Knowledge About Best Battery for High Temperature
Frequently Asked Questions about High Temperature Batteries
LiPo Battery Guide of the Customization ProcessHigh Temperature LiPo Battery FAQ
What makes CMB's high temperature LiPo batteries suitable for outdoor sensors and camera systems?
CMB’s high temperature LiPo batteries are specifically tailored to excel in harsh outdoor environments. They offer high density and exceptional discharge power, ensuring reliable performance even in extreme temperatures.
How do high temperature LiPo batteries differ from standard LiPo batteries?
High temperature LiPo batteries are engineered with materials and designs that allow them to withstand and operate efficiently in elevated temperatures. This includes specialized electrolytes and thermal management features.
Can high temperature LiPo batteries be used in other applications besides outdoor sensors and camera systems?
While they are optimized for outdoor use, high temperature LiPo batteries can also be suitable for other applications where elevated temperatures are a concern, such as industrial monitoring systems .
Are there any special precautions or considerations for using high temperature LiPo batteries?
It’s important to ensure proper ventilation and heat dissipation when using high temperature LiPo batteries. Additionally, users should adhere to manufacturer guidelines for charging and discharging within specified temperature ranges to maintain battery performance and safety.
Can CMB provide custom solutions for high temperature LiPo batteries?
Yes, CMB offers custom solutions tailored to specific application requirements. Our engineering team can work with clients to design and manufacture high temperature LiPo battery packs that meet their unique needs.
What are the benefits of using high temperature LiPo batteries over other battery chemistries?
High temperature LiPo batteries offer advantages such as higher energy density, lighter weight, and faster discharge rates compared to other battery chemistries like NiMH or lead-acid batteries. Additionally, they can provide longer cycle life and better performance in extreme temperatures.
