43.2V 40Ah 21700 Drone Battery Packs
CMB proudly designs and manufactures battery packs specially crafted and equipped for electric surfboards and eFoils. Learn more about our electric surfboard battery offerings below, and reach out to a CMB team member today to get started with your custom battery pack design.
The engineering team of CMB is devoted to designing drone batteries with long-lasting and reliable quality. With a high discharge current and weight limit of 21700 battery pack for drone, we’ll accurately calculate the internal resistance and temperature from the 43.2V 12Ah 21700 battery pack. We’ll consider the 21700 li-ion cells, nickel materials, wiring routes, and BMS solutions to reduce the internal resistance and temperature, which make the 12S 21700 drone batteries with optimal performance and long cycles.
43.2V 12Ah 21700 Battery Pack for Drone Parameter Specifications
| No. | Item | Specification | Note |
|---|---|---|---|
| 1 | Nominal Voltage | 43.2V | 3.6V/Cell |
| 2 | Nominal Capacity | 12.6Ah | @0.2C |
| 3 | Minimum Capacity | 12Ah | / |
| 4 | Initial Internal Impedance | ≤200mΩ | AC 1KHZ |
| 5 | Standard Charge Voltage | 50.4V | 4.2V/Cell |
| 6 | Standard Charge Current | 2.52A | @0.2C |
| 7 | Max. Charge Current | 25A | BMS Limit |
| 8 | Standard Discharge Current | 2.52A | @0.2C |
| 9 | Max. Discharge Current | 63A | / |
| 10 | Discharge Cut-off Voltage | 30V | 2.5V/Cell |
| 11 | Cycle Life | ≥500 cycles | Retention: ≥80% |
| 12 | Charge Temperature | 0°C~60°C | Standard Charge |
| 13 | Discharge Temperature | -40°C ~60°C | Standard Discharge |
| 14 | Storage Temperature | -20°C~ 45°C | ≤3 Months |
| 0°C ~ 25°C | ≤1 Year | ||
| 15 | Weight | About 3.6Kg | / |
The Development Timeline for Custom 43.2V 12Ah 21700 Drone Battery Packs
Preliminary Design
After receiving your initial questionnaire, we’ll create a custom design for your battery. Timeframe: 2 days.
3D Drawing
Next, we’ll provide you with a detailed CAD drawing of your custom battery. Timeframe: 2 days.
Approval of Specifications
We’ll share your battery pack specifications for your approval. Timeframe: 2 days.
Estimate
Next, we’ll create a pricing estimate for you to sign off on. Timeframe: 1 day.
Housing
If your battery pack requires custom housing, we’ll require some additional time to accommodate this request. Timeframe: 8-9 weeks.
BMS Development
We’ll craft a custom battery management system (BMS) for your unique battery to ensure safe and effective performance. Timeframe: 7-10 days for standard BMS, 25-30 days for Smart BMS.
Sample Creation
Next up, we’ll create a sample battery pack for you to sign off on before production. Timeframe: 5 days.
Sample Shipment
Once your sample is ready, we’ll ship it straight to you for approval. Timeframe: 4-7 days.
Certification
We can also assist with obtaining UL certification for your custom battery pack. Timeframe: 2-3 weeks.
- Specifications
-
43.2V 12Ah 21700 Battery Pack for Drone Parameter Specifications
No. Item Specification Note 1 Nominal Voltage 43.2V 3.6V/Cell 2 Nominal Capacity 12.6Ah @0.2C 3 Minimum Capacity 12Ah / 4 Initial Internal Impedance ≤200mΩ AC 1KHZ 5 Standard Charge Voltage 50.4V 4.2V/Cell 6 Standard Charge Current 2.52A @0.2C 7 Max. Charge Current 25A BMS Limit 8 Standard Discharge Current 2.52A @0.2C 9 Max. Discharge Current 63A / 10 Discharge Cut-off Voltage 30V 2.5V/Cell 11 Cycle Life ≥500 cycles Retention: ≥80% 12 Charge Temperature 0°C~60°C Standard Charge 13 Discharge Temperature -40°C ~60°C Standard Discharge 14 Storage Temperature -20°C~ 45°C ≤3 Months 0°C ~ 25°C ≤1 Year 15 Weight About 3.6Kg / - Development Timeline
-
The Development Timeline for Custom 43.2V 12Ah 21700 Drone Battery Packs
To obtain a specific timeline for your custom battery, get in touch with a CMB consultant.Preliminary Design
After receiving your initial questionnaire, we’ll create a custom design for your battery. Timeframe: 2 days.
3D Drawing
Next, we’ll provide you with a detailed CAD drawing of your custom battery. Timeframe: 2 days.
Approval of Specifications
We’ll share your battery pack specifications for your approval. Timeframe: 2 days.
Estimate
Next, we’ll create a pricing estimate for you to sign off on. Timeframe: 1 day.
Housing
If your battery pack requires custom housing, we’ll require some additional time to accommodate this request. Timeframe: 8-9 weeks.
BMS Development
We’ll craft a custom battery management system (BMS) for your unique battery to ensure safe and effective performance. Timeframe: 7-10 days for standard BMS, 25-30 days for Smart BMS.
Sample Creation
Next up, we’ll create a sample battery pack for you to sign off on before production. Timeframe: 5 days.
Sample Shipment
Once your sample is ready, we’ll ship it straight to you for approval. Timeframe: 4-7 days.
Certification
We can also assist with obtaining UL certification for your custom battery pack. Timeframe: 2-3 weeks.
43.2V 12Ah 21700 Drone Battery Pack Applications
Technical Articles Related to 43.2V 12Ah 21700 Drone Batteries
21700 VS 18650 Batteries for Real-world Applications
A Comprehensive Guide: High Rate Discharge LiPo Batteries
A Comprehensive Knowledge About Best Battery for High Temperature
How to Choose the Right Battery for Low Temperature Conditions43.2V 12Ah 21700 Battery Pack for Drone FAQ
How long is the battery life of CMB’s 43.2V 12Ah 21700 drone battery packs?
Battery life can depend on usage, maintenance, and operation modes, but generally speaking, these battery packs have a lifespan of 200-500 charge cycles.
Does CMB offer custom 21700 battery packs for drones?
Absolutely. CMB specializes in crafting custom battery packs for all sorts of applications, including for drones. Please fill out our customization questionnaire so we can begin designing your unique drone battery pack.
What kind of lithium-ion charger is compatible with 43.2V 12Ah 21700 battery packs for drones?
50.4V 4A li-ion chargers are compatible with these types of battery packs. Using these compatible chargers, your battery will take 4-5 hours to fully charge.
